Dual 1x2 Fiber Optical Switch
Name:

Dual 1x2 Fiber Optical Switch

Class:
Micro Mechanical Optical Switch
Type:
D1x2 Optical Switch

Dual 1x2 Fiber Optical Switch Specification
optic-switch.com - Company  Profile-2010



dual 1x2 optical switch

optic-switch-fsw-dual 1×2 optical switch, which is famous for its great performance, low insertion loss and compact dimension : 27.0×(w)12.6×(h)8.0.it is an ideal component for oadmoxcsystem monitor and protection. with compact package, it could be easy to integrate into a high density optical communication system.




features

·low insertion loss

·wide wavelength range

·low crosstalk

·high stability, high reliability

·epoxy-free on optical path

·latching and non-latching

   applications

·metropolitan area network

·r&d in laboratory

·system monitoring

·configurable oadm



performance



parameters



optic-switch-fsw-d1×2

wavelength range

nm

670980

12601650

testing wavelength

nm

670/785/850/980

1310/1490/1550/1625/1650

insertion loss

db

typ:0.8  max:1.2

typ:0.5  max:1.0

return loss

db

mm≥30   sm≥50

crosstalk

db

mm≥30   sm≥55

pdl

db

≤0.05

wdl

db

≤0.25

tdl

db

≤0.25

repeatability

db

≤±0.02

power supply

v

3.0 or 5.0

lifetime

time

≥107

switch time

ms

≤8

transmission power

mw

≤500

operation temperature

-20+70

storage temperature

-40+85

weight

g

16

dimension

mm

(l)27.0×(w)12.6×(h)8.00.2mm)      customization is available.















































pins

control model

optical path

electric drive

status sensor

d1×2

light pin

1

5

6

10

2-3

3-4

7-8

8-9

latching

p1-p2

p1’-p2’

--

--

gnd

v+

close

open

open

close

p1-p3

p1’-p3’

v+

gnd

--

--

open

close

close

open

non-latching

p1-p2

p1’-p2’

--

--

--

--

close

open

open

close

p1-p3

p1’-p3’

v+

--

--

gnd

open

close

close

open



ordering information    optic-switch–fsw-d1×2-a-b-c-d-e-f-g-h

a

b

c

d

e

f

g

h

mode

wavelength

voltage type

control model

fiber type

fiber diameter

fiber length

connector

s:sm

m:mm

85: 850nm

13: 1310nm

14: 1490nm

15: 1550nm

162: 1625nm

165: 1650nm

13/15:1310/1550nm

x: others

3: 3v

5: 5v

l: latching

n: non- latching

5:50/125

6:62.5/125

9: 9/125

x: others

25:250um

90:900um

x: others

05:0.5m

10:1.0m

15:1.5m

x: others

oo: none

fp: fc/pc

fa: fc/apc

sp: sc/pc

sa: sc/apc

sp: st/pc

sa: st/apc

lp: lc/pc

la: lc/apc

x: others



Welcome to contact our engineers to know more info about the specification.

** You can click 'getOffer' or 'AddToCart' button to get the formal offer document directly.
** If you are agent / OEM / middle trade, please copy the specification into word document from our website ,then send it to your clients.
